Latest documents
DARTs – An analysis tool for Disaggregated RAN Transport
The aim of this paper is to help deployers plan, design and budget for transport networks in different deployment scenarios. In the paper we discuss the details of the interfaces of different splits and their transport bandwidth requirements. We also discuss parameters which affect transport bandwidth calculations and their default values.
Download Find out more
Options for split RAN: Flexibility within a common framework
This high-level and approachable white paper argues that, despite the flexibility of open interfaces and APIs, there is a strong case for at least two options in terms of open RAN platforms, and that this is borne out by deployer survey data. And that this is especially vital in enterprise markets where no single solution will fit all scenarios.
Download Find out more
5G FAPI Operations, Administration and Maintenance (OAM) Protocol for Inline High-PHY
In the context of Open RAN, the FAPI operations and maintenance (OAM) interface brings fuller virtualized support of inline High-PHY implementations in O-RAN Alliance architecture. The O-RAN fronthaul M-Plane typically terminates in L2/L3, requiring the FAPI suite to convey O-RAN M-Plane content between L2/L3 and L1. This new iteration has been streamlined to align with SCF222.
Download Find out more
5G FAPI: PHY API specification
PHY FAPI is the main API for FAPI, defining P5 and P7 interfaces for user and control plane into the PHY. Its typical application is between a PHY layer System on a Chip and the software stack for MAC and higher layer protocols. It can also be used to enable Embedded NIC Inline Accelerators for the High-PHY function in an O-RAN DU. This latest iteration includes support for 3GPP Rel-16 Remote Interference Management (RIM) and new high-resolution L1 Metrics (RSSI, RSRP and Noise+Interference): to assist the scheduling and automated logging functions.
Download Find out more
5G FAPI: P19 RF and digital frontend control API
This P19 interface specification serves as a companion to the 5G FAPI P5/P7 specification. Besides enabling the fast, dynamic control of the FEU, one of the primary goals of P19 is to facilitate network virtualization by allowing stack and FEU solutions from different vendors to bind together easily. The concept applies to both the all-in-one small cell solutions where the upper, the lower layers and the FEU are all colocated, as well as the disaggregated solutions where they may reside at different physical locations.
Download Find out more
5G nFAPI specifications
The 5G network functional application platform interface (5G nFAPI) is an initiative that extends for 5G the functional split between the MAC and PHY functions that enables virtualization of the MAC function.
Download Find out more
Neutral Host Requirements: Pt 2 Hosted RAN high-level design
SCF245 Neutral host requirements part 2: Hosted RAN high-level design, aims to globalize and build on the ground-breaking work initiated by the UK’s MNOs’ Joint Operator Technical Specification for Neutral Host In-Building (JOTS NHIB). However Hosted RAN is applicable for a range of tenants not just Mobile Network Operators, but also private network operators, MVNOs and enterprises, and is for indoor and outdoor coverage.
Download Find out more
Small Cell Open RAN: A catalyst for new 5G business models
Open RAN is an important step toward the democratization of radio access networks (RANs). This document aims to provide a crisp and accessible overview of Small Cell Open RAN – what it is and what it’s not, along with a short overview of SCF activities in this space. It provides important market research data, shedding light on how various Open RAN solutions are addressing diverse usage, deployment and operational scenarios. The document finishes with case studies of operational deployments, tests and trials by SCF members.
Download Find out more
5G NR FR1 Reference Design
This paper sets out the case for a common, modular architecture for 5G NR FR1 small cell distributed radio units. It provides a comprehensive overview of the components and interfaces that comprise a 5G NR FR1 small cell distributed radio unit within the context of a reference design.
Download Find out more
How blueprints unlock the potential of 5G networks
This describes the SCF roadmap for a series of technical and deployment blueprints that will provide common reference designs and deployment processes that reduce the time, cost and risk of developing a small cell network. While based on standard specifications, the blueprints will be specific to certain roll-out scenarios that are not currently addressed by the frameworks of other organizations. The first blueprints will focus on private networks.
Download Find out more
